用于PET瓶的三合一机器将冲洗，灌装和封盖的功能集成在一起。基于国外先进技术，并根据注水加工要求设计
主要特点
1. This machine has a compact structure, completed control system, easy to operate and highly automated.
2. By changing the star-wheel, screw bottle inlet and arc guide plate can realize to change the bottle shape.
3. The parts that direct contact with product are made of food grade stainless steel and no technology corner pockets and easy to clean.
4. By adopting high speed filling valve, the liquid level is precise and no waste. That guarantees the demand of filling technology.
5. The machine adopts high effective cap sorting system and completely self control and protective device.
6. The machine is equipped with perfect overload protective device that can keep the equipment and operator safely.
7. The control system has many functions, such as control producing speed, cap shortage detection, bottle block automatic stop and production counting etc.
8. The electric components and pneumatic components are all introduced from world famous brand products.
| 工作岗位数量 | 冲洗32，填充32，加盖10 |
| 生产能力 | 15000BPH（500ml）中 |
| 气源压力 | 0.7兆帕 |
| 耗气量 | 1.2立方米/分钟 |
| 冲洗水压 | 0.2-0.25Mpa |
| 冲洗水容量 | 2.5T / H |
| 主电机功率 | 3.2KW |
| 总功率 | 4.8千瓦 |
| 尺寸 | 4250X2150X2200mm（长×宽×高） |
| 重量 | 5200公斤 |
我们还提供全自动纯净水灌装厂
它包括4个主要部分：
1. Plastic bottle blow molding machine
2. Water cleaning system
3. Water washing, filling, capping machine.
4. Conveyor system, labeling machine, dating machine, film wrapping machine
完整的行主要描述：
1. The plant can produce different volume bottles, from 200ml to 2000ml bottles, round and square bottles, plastic and glass bottles. It is very easy to change the different bottle molds.
2. The plant is highly automatic, you can operate on the touch screen to adjust the machine speed and working.
3. We have different speed plants, commonly, 2000BPH, 4000BPH, 7000BPH, 10,000BPH, 15000BPH..ect.
4. The material is stainless steel 304, food grade much clean and safe.
5. We provide the engineers for customer installation, training in customer's factory.
型号和速度列表
| 模型 | XGF8-8-3 | XGF14 / 12/5 | XGF16 / 16/5 | XGF24 / 24/8 | XGF32 /一十分之三十二 |
| 洗手 | 8 | 14 | 16 | 24 | 32 |
| 灌装阀门 | 8 | 12 | 16 | 24 | 32 |
| 封顶的手 | 3 | 5 | 5 | 8 | 10 |
| 合适的PET /玻璃瓶（150ml至2000ml） | |||||
| 能力（速度） 基于500毫升 | 2000BPH | 5000BPH | 7000BPH | 12000BPH | 15000BPH |
电气元件品牌供应商
| 主要成分 | 描述供应商 |
| PLC | 三菱（日本），西门子（德国） |
| 触摸屏 | 威纶（台湾） |
| 频率转换器 | 三菱（日本），西门子（德国） |
| 空气开关 | 施奈德（法国） |
| 断路器 | 西门子（德国） |
| 接触 | 西门子（德国） |
| 光电开关 | 欧姆龙（日本） |
快速详情
类型：灌装机
成色：全新
应用：饮料，化学，医疗
包装类型：瓶子
包装材料：塑料
自动等级：自动
驱动类型：电动
电压：380V / 220V
功率：4.8KW
产地：中国上海（大陆）
品牌名称：VKPAK
尺寸（长*宽*高）：4250X2150X2200mm
重量：5200KGS
认证：CE，ISO，SGS
提供售后服务：工程师可在海外维修机械
工厂：LINKS MACHINERY
瓶子大小：150ml至2000ml
瓶颈直径：15-55mm
瓶子材料：塑料/玻璃
速度（基于500毫升瓶装）：15000B / H.
控制系统：PLC触摸屏（MITSUBISHI JAPAN）
盖：螺丝/压盖
盖帽电梯：有
填充液体：矿物质/纯净水
