A dishwashing liquid filling machine is a type of automated equipment that is designed to fill bottles or containers with dishwashing liquid. It typically uses a series of pumps, sensors, and nozzles to accurately measure and dispense the correct amount of dishwashing liquid into each container. These machines can be used in industrial or commercial settings to increase production efficiency and accuracy.
产品规格
洗碗液灌装机
1. With CE Certificate,Meet the GMP
2. Material:304or316Stainless Steel
3. Pay:T/T,L/C
描述
欧盟的CE
ISO9001
符合GMP要求
longlife of service, low mainteinance rate
主功能
该机是先进的高精度灌装机，可自动完成瓶子计数，灌装和封盖过程。
特征
1.结构紧凑，美观，易于操作，高度自动化。
2.元件接触材料均采用不锈钢制造，便于清理。
3.填充量由薄膜阀控制，以确保准确性。
4.高速，高精度的灌装阀确保无泄漏。
5.配备高效的盖帽喂料系统。
语言选择
Monitor language: English, Spanish, Arabic, Portuguese, Russian, Italian, French, Korean.
主要特点：
1. Linear type piston filling machine special designed for sticky liquid,such as detergent, shampoo, lotion,lubricant oil,edible oil, etc. international advanced technology, already approved by well-known companies such as Bayer. High filling accuracy, simple structure, stable working, widely application. Counting of bottles inlet, qualitative filling, bottles outlet are done automatically.
2. Not only the whole 13 filling nozzles dosage can be rough adjusted, but also each single filling nozzles dosage can finely adjusted.
3.可记忆多个参数，有助于各种规格变更，所有灌装剂量均可通过触摸屏调节。
4. Liquid control for normal working liquid level control, sound and light alarm device, guarantee the liquid level at normal condition; also can achieved for inlet valve/pump control.
5. Material outlet joints all adopts quick-assembling type (clamp type), easily for clean. Sealing gaskets adopts fluorine rubber O-ring; sanitary connecting pipes.
6. With protection case, drip gutter, main materials are made of SS304, wetted parts are made of SS316L.
主要技术参数
| 项目 | 名称 | 技术参数 |
| 01 | 机器尺寸（长*宽*高） | 2200毫米*1400毫米*2800毫米 |
| 02 | 机器重量 | 约1400Kg |
| 03 | 容器开口内径 | ≥φ35mm |
| 04 | 合适的容器 | 1升.2升 |
| 05 | 集装箱高度 | 80-350mm |
| 06 | 电源 | AC 380V; 50HZ |
| 07 | 功率 | 5KW |
| 08 | 填充准确性 | ≤±1％ |
| 09 | 空气源 | 0.6Mpa稳定，清洁的压缩空气 |
| 11 | 灌装喷嘴数量 | 13 |
| 12 | 输送机高度 | 900毫米±50毫米 |
| 13 | 容量 | ≤3200瓶/小时（以水为试验） |
| 14 | 瓶子在进料方向 | 从左到右 |
快速详情
类型：灌装机
条件：新的
适用范围：化工
包装类型：瓶子
包装材料：木材
自动等级：自动
驱动类型：气动
电压：220v
功率：3KW
产地：上海。中国（大陆）
品牌名称：VKPAK
尺寸（长*宽*高）：2200mm * 1400mm * 2800mm
重量：1400
认证：CE
提供售后服务：工程师可在海外维修机械
材料：SS304
PLC：松下
触摸屏：松下
Dishwashing liquid filling machines are specifically designed to package dishwashing liquids into various types of containers. These machines are essential for businesses in the cleaning industry who want to streamline their packaging process and increase their productivity. There are several types of dishwashing liquid filling machines available in the market, each with its unique features and benefits.
One of the most popular types of dishwashing liquid filling machines is the volumetric filler. This machine operates on the principle of displacement and uses a piston to fill the containers with the precise amount of liquid required. This type of machine is highly accurate and is suitable for packaging liquids with a constant viscosity.
Another type of dishwashing liquid filling machine is the gravity filler. This machine works on the principle of gravity and uses a funnel to fill the containers with the liquid. The liquid is then dispensed into the containers based on the height of the liquid in the funnel. This type of machine is ideal for packaging low viscosity liquids and is very cost-effective.
The third type of dishwashing liquid filling machine is the overflow filler. This machine works on the principle of overflow and uses a hopper to fill the containers with the liquid. The liquid is then dispensed into the containers based on the height of the liquid in the hopper. This type of machine is ideal for packaging high viscosity liquids and can handle liquids with large particles.
When choosing a dishwashing liquid filling machine, it is important to consider factors such as the size of your production line, the viscosity of the liquid, the type of containers you will be using, and the speed of production you require. It is also important to consider the ease of maintenance and the reliability of the machine.
In conclusion, a dishwashing liquid filling machine is a crucial investment for businesses in the cleaning industry. With the right machine, businesses can increase their productivity, improve the quality of their packaging, and save time and money. When choosing a dishwashing liquid filling machine, it is important to consider factors such as the size of your production line, the viscosity of the liquid, the type of containers you will be using, and the speed of production you require.
